مشخصات فنی
3 + 1 BLE
5 Internal + 1 BLE Internal
PIFA: 4 dBi for 2.4 GHz, 5
dBi for 5 GHz
2.400–2.4835, 5.150–5.250, 5.250–5.350, 5.470–5.725,
5.725–5.850
Frequency Band: 2.4 GHz
Channel width: 4×4 20/40 MHz
Modulation: BPSK, QPSK, QAM64, QAM256, and QAM1024
MIMO chains: 4×4 service
Frequency Band: 5.0 GHz
Channel width: 4×4 20/40/80MHz and 2×2 160MHz
contiguous
Modulation: BPSK, QPSK, QAM64, QAM256, and QAM1024
Mimo chains: 4×4 service
Frequency band: 2.4/5.0 GHz
MIMO chains: 1×1 frequency scanning
Radio 1: up to 1147 Mbps
Radio 2: up to 2402 Mbps
Radio 3: scan only
Bluetooth scanning and iBeacon advertisement @ 6 dBm
max TX power
• 802.3at PoE default
• 1 port powered by 802.3at or 2 ports powered by 802.3af
– Full System functionality + USB support
• 1 port is connected to 802.3af – No USB support, Operate
in 2×2 mode with reduced power R1/R2 17dBm(Tx power)
EAP-TLS, EAP-TTLS/MSCHAPv2, PEAPv0/EAP-MSCHAPv2,
PEAPv1/EAP-GTC, EAP-SIM, EAP-AKA, EAP-FAST
WPA™, WPA2™, and WPA3™ with 802.1x or Preshared key,
WEP, Web Captive Portal, MAC blocklist and allowlist
Radio 1: 2.4 GHz 24 dBm / 251 mW (4 chains combined)
Radio 2: 5 GHz 23 dBm / 200 mW (4 chains combined)
Radio 3: NA
802.11a, 802.11b, 802.11d, 802.11e, 802.11g, 802.11h,
802.11i,802.11j, 802.11k, 802.11n, 802.11r, 802.11v, 802.11w,
802.11ac, 802.11ax (Wi-Fi 6), 802.1Q, 802.1X, 802.3ad,
802.3af, 802.3at, 802.3az, 802.3bz
Local-Bridge, Mesh, Tunnel
512 per Radio1 and Radio2
1x 100/1000/2500 Base-T RJ45,
1 x 10/100/1000 Base-T RJ45,
1x Type A USB, 1x RS-232 RJ45 Serial Port
یاسری –
از FORTIAP-431F در چه scale استفاده میشود
رضا –
اکسس پوینت فورتی نت FortiAP-431F برای چه محیط هایی مناسب است ؟
ادمین سایت –
FortiAP-431F برای محیطهای داخلی طراحی شده است.
رضاوند –
تعداد اینترفیس های اکسس پوینت فورتی نت FortiAP-431F چند عدد است ؟
ادمین سایت –
اینترفیسهای اکسس پوینت فورتی نت FortiAP-431F به شرح زیر است:
دو عدد 100/1000/2500/5000 Base-T RJ45
یک عدد Type 3.0 USB
یک عدد RS-232 RJ45 Serial Port
داوود –
ممنون از مطالب خوبتون
